PLEASE CHECK THE FOLLOWING BEFORE CALLING YOUR SERVICE CENTER
Before troubleshooting, the pool cleaner must be disconnected from the power supply and the power supply must be unplugged from the
electrical outlet to prevent damage to the unit and possible personal injury.
For reference numbers, consult the parts list diagram located on the last page of the instructions.
1. Unit does not pump water or move:
2. Unit does not pump water at all, or pumps slowly
but moves:
a) Check to see if electric outlet (22) has power.
b) Check if transformer (16) is plugged into a grounded outlet
and the blue cable assembly is plugged into the
transformer.*
c) Switch the power supply “OFF” (19) and “ON” (21) buttons
a few times. Allow 45 seconds between “ON” and “OFF”.
d) Check for and remove any debris such as hair, string, or
leaves that may be obstructing the free movement of the
Drive Pulley (5), Drive Belts (6) , or Drive Tracks (7) .
e) Check that the Drive Belts (6) and Drive Tracks (7) are
properly aligned and are taut. Adjust or replace if
necessary.
*The transformer cord can only be replaced with the aid of special purpose tools normally available only to authorized dealers, distributors and service centers.
a) Check to see if propeller (1) is seized due to accumulation
of hair or debris on the propellers. Remove the top screws on
each outlet top (1) and clean the propeller. When
reassembling the top cover, do not overtighten the screws.
b) Check to see if the filter bag (12) is thoroughly clean.
Clean as necessary.
c) If a and b are negative, check the pump motors (2). If
they are not functioning send the unit to your service
center.
6
