6
Installation
5. Screw the telescopic rods (TR-12) into the mounting blocks on the
MT-BLACK mounting plate.
Mounting the Monitor
The Legacy Backplate has 3 mounting positions.
a. Sony / Panasonic (Top)
b. MT RED / Hitachi (Middle)
c. MT BLACK (Bottom)
!
CAUTION! It is advised that two people attach the monitor
to the telescopic rods, one supporting the monitor while
the other screws in the rods.
