Avanti F18D0W - Preparing the Refrigerator for Icemaker Installation

Tools Required:
Putty Knife
Pliers
¼ inch Socket Wrench
Needle Nose Pliers or Nut Driver
Adjustable Wrench
Knife
Flat Screw Driver
1
Disconnect the unit from the electrical supply.
2
Remove ice tray rack from freezer.
3
Move the freezer shelf to the next position.
5
4
Carefully Remove the plugs / label from inside the freezer
compartment using a putty knife.
6 Peel away the label covering the ice-maker installation
hole.
7
Using a pair of needle nose pliers, remove the foam from
the hole.
8
Insert the water inlet tube into the small hole on the back of
the refrigerator. Rotate the hose while inserting until the
flat surface of the hose is secure against the back of the
refrigerator.
In order to remove the plug, you need to squeeze the two
ends and pull the plug out, or need to use the tools such as
a flat screw driver or needle nose pli
Plug
er.
