Avantone Pro CK-40 - Standard Items Supplied; Specifications

used on vocals and single instruments. The omni mode works well in incorporating some room sound into
the track. The figure 8 pattern allows 2 vocalists to use the mic at the same time from opposite sides. The
figure 8 pattern also enables the CK-40 to be used in tandem with a second CK-40 or other cardioid mic in
order to implement the M-S Stereo miking technique.
The -10d8 attenuation switch can be engaged when miking very high SPL sources to keep from overloading
the electronics.
The 80Hz HIGH-PASS filter switch can be engaged to reduce rumble and to keep unwanted low frequencies
from "muddying up" the track.
STANDARD&ITEMS&SUPPLIED&
• AVANTONE CK-40 Stereo FET Microphone
• AVANTONE Custom Retro Shockmount with extra elastic bands
• 1X2 Splitter Box (Stereo Breakout Box)
• Elegant padded genuine wooden Mic box
• 30’ 5-pin cable
• Foam wind filter
• Padded Aluminum storage / travel case
• Owners Manual
!
SPECIFICATIONS&
Type:
Stereo True Condenser
Polar Pattern/s:
Cardioid, Omni, Figure 8 (x2)
Frequency Response:
20-20,000Hz +/- 3dB
Output Impedance:
<=250 Ohms / transformer isolated
Maximum SPL :
147dB (0.5% THD @ 1000Hz)
Equivalent noise level
17dB (A weighted EC651)
S/N Ratio re 1Pa :
77dB
Sensitivity
-40dB
Output Connector:
Male XLR 5 pin with included breakout box and cable
High-Pass Switch
80 Hz 6dB/octave
Attenuation Switch
-10dB
Included Accessories:
Wood Box, Shockmount, Foam Filter, 2x1 splitter box, 30’
cable, Metal Road Case
Power Requirement:
Standard 48 Volt Phantom (x2) 3mA current consumption
Weight:s.
.95kg / 2.1 lb
Dimensions:
27.6cm x 49mm (10-7/8” x 1-15/16”)
Finish:
Polished Nickel trim / Metallic Cabernet Red Body
Specification and design subject to change for improvement purposes without prior notice E&OE
