Avantone Pro CV-12 - Specifications

STANDARD ITEMS SUPPLIED
 AVANTONE CV-12 Tube Microphone
 AVANTONE Custom Retro Shockmount
 AVANTONE PS-12 Multi-Pattern Power Supply with cables
 Elegant padded genuine wooden Mic box
 Padded Aluminum storage / travel case
 Owner’s Manual
SPECIFICATIONS
Type:
Tube-Type True Condenser
Capsule:
Dual-sided 32mm center-terminated gold-sputtered Mylar (6
micron)
Polar Pattern/s:
9 Patterns selectable at PS-12 Power Supply
Frequency Response:
20-20,000Hz +/- 3dB
Output Impedance:
<=250 Ohms / transformer isolated
Maximum SPL :
136dB (0.5% THD @ 1000Hz) 146dB with pad engaged
Equivalent noise level
17dB (A weighted EC651)
S/N Ratio re 1Pa :
78dB
Sensitivity
-38dB
Output Connector:
Male XLR 7 pin with special power supply and cables
High-Pass Switch
80 Hz 6dB/octave
Attenuation Switch
-10dB
Included Accessories:
Wood Box, Shockmount, 7-pin cable, metal Road Case, PS-12
Power Supply
Power Requirement:
Dedicated PS-121 Power Supply, 115/230VAC selectable
Weight:s.
.8kg / 1.8 lb.
Dimensions:
237mm x 46mm (9.5” x 1.8”)
Finish:
Polished Nickel trim / Metallic Cabernet Red Body
Specification and design subject to change for improvement purposes without prior notice E&OE
