This document describes the Avenlur Walnut by Avenlur, a children's indoor playground equipment designed for active play and development. It features a combination of climbing elements, including a ladder, a climbing wall with colorful holds, and a rope net. The set also includes a slide and a swing, providing a comprehensive play experience.

Function Description:

The Avenlur Walnut is an indoor playground designed to encourage physical activity, coordination, and strength in children. It provides a safe and engaging environment for climbing, swinging, sliding, and imaginative play. The various components offer different challenges, helping children develop gross motor skills, balance, and problem-solving abilities. The climbing wall with its colorful holds allows for varied climbing routes, while the rope net offers a different texture and climbing experience. The ladder provides a traditional climbing option, and the swing adds an element of fun and vestibular stimulation. The slide offers a quick and enjoyable descent.

Important Technical Specifications:

Maximum User Weight: 220 lbs (100 kg) per child.
Overall Dimensions (Top View):
- Width: 77.1 inches
- Depth: 25.6 inches
- Height: 78.8 inches
Overall Dimensions (Angled View with Slide):
- Width (including slide extension): 65.3 inches
Materials: Primarily wood for the main structure, with ropes for the net and swing, and plastic/composite materials for the climbing holds and slide.
Assembly: Adult assembly required. An electrical drill is recommended for assembly.
Hardware: A variety of screws and bolts are used for assembly, including M6.3x40, M6x120, M6x20, M8x100, M8, M10x40, M4x40, M10x35, M6x80, M4, M10. Specific quantities are provided for each hardware type.
Components:
- Wooden planks/beams of various lengths (e.g., 23.3in, 24.4in, 25.4in, 26.5in, 29.1in, 37.4in, 39.4in, 45.2in, 45.3in, 51.2in, 189in, 322.8in).
- Climbing holds (29 pieces).
- Rope elements (2 pieces, 189in and 322.8in).
- Swing (1 piece).
- Slide (1 piece).
- Ladder rungs (18 pieces).
- Support brackets and connectors.

Usage Features:

Adult Supervision: Always requires adult supervision during use by children of all ages.
Weight Limit: Strictly adhere to the maximum user weight of 220 lbs (100 kg) per child.
Safety Precautions:
- Do not attach items to the playground equipment that are not specifically designed for use with it (e.g., ropes, clotheslines, pet leashes, cables, chains) as they can pose strangulation or other hazards.
- Children should not use the equipment in any manner other than intended.
- Keep small assembly parts out of reach of children due to choking hazard.
Installation:
- It is recommended to have at least two people for assembly to ensure all sides and parts are leveled.
- Avoid over-tightening screws to prevent wood splintering.
- Follow directions carefully.
- For wall attachment (Step 11-1), use a stud finder to locate wall studs (typically 16" apart). Measure the distance between studs to confirm. Mark, level, and predrill holes in the wall before attaching parts with screws.
Play Elements:
- Climbing Wall: Features colorful climbing holds for varied grip and foot placement.
- Ladder: Provides a traditional climbing experience.
- Rope Net: Offers a flexible and challenging climbing surface.
- Swing: Allows for swinging motion.
- Slide: Provides a fun way to descend.

Maintenance Features:

Periodic Inspection: Inspect the product periodically for loose or damaged components.
Tighten Bolts: Tighten bolts as needed.
Connection and Bolt Check: Check all connections and bolts for tightness at least twice monthly during usage.
Edge Check: Check all coverings and bolts for sharp edges.
Discontinue Use: Do not use the equipment if screws are loose or if any components are damaged.

Self-Provided Tools for Assembly:

Pen
Drill
Studfinder
Measuring tape
Level

Contact Information for Support:

Phone: 888.697.3931 (M-F 9AM - 5PM PT / 12PM - 8PM ET)
Email: info@avenlur.com
Contact for assembly questions, missing parts, or damaged parts. Installation video reference is available upon request.

avenlur Walnut - Page 15
