Model E1010 Indicator Service Manual
The next section of the Service menu is the INPUT submenu. See Figure
11. This menu lets you configure the inputs of the indicator.
INPUT submenu
Figure 11
INPUT submenu
Follow these steps to access and configure the inputs:
1. Access the Service menu. . .
CAL is displayed.
2. Press the UNITS key repeatedly until. . .
INPUT is displayed.
3. Press the PRINT key. . .
1 is displayed. This stands for input #1. You can scroll to each
input by using the UNITS key or TARE key. When you access
each input, by pressing the PRINT key, you get to choose from
this list of input types:
NONE No input
ZERO Performs a ZERO key press
TARE Performs a TARE key press
PRINT Performs a PRINT key press
UNITS Performs a UNITS key press
F1KEY Performs a F1 key press
T.CNCEL Cancels the active tare
4. Scroll through the choices by using the UNITS key or TARE key and
press the ENTER key to accept the displayed choice. .
INPUT is displayed.
This completes the INPUT submenu. Press the UNITS key to go to the
OUTPUT submenu or press ZERO to return to normal weighing mode.
Service Menu—INPUT submenu
