53
Model E1010 Indicator Service Manual
AUDIT submenu
(Audit counters)
CFG
(Configuration audit counter)
CAL
(Calibration audit counter)
SLEEP submenu
(Sleep mode)
Supervisor Menu (continued)
When the indicator goes to
sleep you must press the
ON/OFF switch to restart the
indicator.
Any motion or any key press
restarts the sleep timer.
25. Repeat steps 21 and 22 for outputs 2 and 3. At step 21, use the TARE or
UNITS key to scroll to the desired output.
26. Press the SELECT key…
OUTPUT is displayed.
This completes the TEST menu item. Press the SELECT key to go to TEST,
then press the UNITS key to go to the AUDIT submenu or press ESC to
return to normal weighing mode.
The next section of the Supervisor menu is the AUDIT submenu. This menu
lets you view configuration and calibration audit counters. These counters
cannot be changed, only viewed. They are a record of configurations and
calibrations performed on the indicator.
Follow these steps to access each item in the AUDIT submenu:
1. With AUDIT displayed, press the PRINT key…
CFG is displayed. This stands for the Configuration audit counter.
Use this item to see how many times this indicator has been
configured.
2. Press the PRINT key…
A number is briefly displayed, then CFG is displayed. This is the
number of times this indicator has been configured.
3. Press the UNITS key…
CAL is displayed. This stands for the Calibration audit counter.
Use this item to see how many times this indicator has been
calibrated.
4. Press the PRINT key…
A number is briefly displayed, then CAL is displayed. This is the
number of times this indicator has been calibrated.
5. Press the SELECT key…
AUDIT is displayed.
1. Press the UNITS key…
SLEEP is displayed. This stands for the sleep mode timer.
2. Press the PRINT key…
Current sleep timer value is shown. Scroll through the choices (1/2,
2, 4, or OFF) by pressing the TARE or UNITS key. Choose OFF to
disable sleep mode. Choose any of the other values to enable a
sleep mode after the chosen time of keyboard inactivity and no
scale motion.
3. Press ENTER when choice is displayed…
SLEEP is displayed.
This completes the Sleep item and the Supervisor menu.
Press ESC to save and return to normal weighing operation.
