AVF Group 469193 - Page 2

Assembly Overview
Fit the Wall Rail
Solid Wall
Wood Stud
Suitable Wall Types
Marking Wall for Drill Points
Hang the TV
Fit the TV Brackets
Use Height Calculator result to position these drill holes
When mounting to a solid wall,
attach the wall plate using all four holes marked
JXPL401 469195
