Fitting the TV Mounting Plate
4
No Spacers Spacer
For TVs with
flat/unobstructed back
For TVs with irregular/obstructed back
K1-K2
TV
TV
TV
TV
WARNING
After completing step 4 you will have fittings left over, please keep
for future reference
!
Before you fully tighten the TV mounting plate please check that the
mounting plate holes line up with the fixing holes on the back of your TV.
Holes do not line up and
small adjustment is required
before you fully tighten
Holes line up and no
adjustment is required
before you fully tighten
