AVF JNL655 - Page 12

Ø3mm
70mm (23/4")
Ensure bracket is in the centre of the wood stud
!
Remove dust
from hole
70mm
(23/4")
Ø12mm
(do not use ½" drill bit)
8mm (5/16") MAX
Fitting the Wall Bracket
5
!
Take care
!
Take care
A
Wood Stud
A
Solid Wall
