AVF NUL404 - Page 12

Fitting the Wall Bracket
4
75mm (3")
Ø10mm
(25/64")
Ø3mm
(1/8")
Ensure bracket is in the centre of the wood stud
!
Remove dust from hole
A
A
75mm
(3")
3x Top
1x Bottom
3x Top
1x Bottom
Solid Wall Wood Stud
