7
Displacement 2210cc
Bore 97.5mm
Stroke 74mm
Compression Ratio 8.3
Rotation of Prop Shaft Clockwise - Pilot's View – Tractor
Ramp Weight
60kg (132lb) inc. Exhaust, Carburetor, Starter Motor, Alternator
& Ignition System & Accessory pack.
Ignition Timing fixed @ 25° BTDC
Firing Order 1-3-2-4
DC Output 10amps - Single Phase
Power Rating 60kw (80hp) @ 3300rpm
Fuel Consumption
Cruse power 0.46 lbs per horsepower hour (274 grams/Kw-
hour at cruse power.)
Fuel AVGAS 100/130LL
Oil AeroShell W100 or 15W50 or equivalent aircraft grade oil
Oil Capacity 2.3l (2.2 Quarts)
Oil filter Ryco Z386 or FRAM PH4967
Spark Plugs NGK D9EA – Automotive
CHT
Cruise 150°C / 300°F
Climb 175°C / 350° F
EGT
Max (Climb) 750° C
Normal (Cruise) 700 ° C
Oil Temp
Max 118°C / 244° F
Continuous 100° C / 212° F
Oil Pressure 220 – 525 KPa / 31 – 76 PSI
Max RPM 3300
Idle RPM 900
