AVM Fritz!Box 7490 Configuration Guide

!
Router!Configuration!Guide!
!
2
Prerequisites$
This$guide$is$for$congregations$with$ADS L$or$VD SL $conn ec tions.$Be fore $starting $this$step$b y$step$process,$
please$power$up$your$router$and$connect$to$the$default$WiFi$connection$provided.$These$details$can$be$
found$in$the$product$box.$If$you$have$a$Fibre$connection,$please$see$the$note$under$Step$8.$
The$following$co n fig u r a tio n $steps$w ill$pro v id e $y o u $with$an$op timized$con fig u ra t io n $fo r $y o u r $K in g d o m$
Hall.$This$process$will:$
1. Ensure$that$Vattendance$VoIP$traffic$is$prioritized,$allowing$the$clearest$sound$possible.$
2. Provide$separate$SSID’s$for$Administrators$and$Guests$(everyone$else)$to$ensure$that$network$
traffic$that$is$critical$to$the$meeting$is$ separa ted$ fr om $ge ne ral$traffic.$
3. Employ$a$basic$web$content$filtering$system$that$blocks$explicit$material.$
$
1 In$your$internet$browser,$browse$to$address$
“http://fritz.box”.$Select$“English”$and$click$“Next”.$
!
2 Select$your$country$and$click$“Next”$
!

AVM Fritz!Box 7490 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	No
Frequency range	2.4 - 5 GHz
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	2
WLAN data transfer rates supported	450, 1300 Mbit/s
Ethernet LAN (RJ-45) ports	4
DHCP client	-
Security algorithms	WPA2, WPS
Power consumption (typical)	9.3 W
Product color	Red, Silver
Cables included	DC, LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	175 mm
Width	245 mm
Height	55 mm
Weight	- g
