VGA/AUDIO: VGA input and audio input
when VGA input.
HDMI1 Input: Digital signal input from
HDMI video connector
13.
15.
16.
17.
Y Pb Pr:
Connect to the composite
terminal of your DVD/VCR
AC power input socket
HDMI2 Input
USB Input
VIDEO/R/L: external AV signal input
and relevant right/left sound channel.
18.
14.
COAXIAL
SCART
ANT 75: Connect the antenna/cadle
TV input(75/VHF/UHF)
: Turn on/off POWER
MENU: Display main MENU and
confirm MENU item selection
CH+/-: Selecting channel
VOL+/-: Adjusting Volume
External signal input
selection
HDMI3 Input
17
18
16
13 15
9 8 12 6
1110
7
14
2
3
45
1
HDMI3
COAXIAL
Pb
Y
Pr
HDMI2
HDMI1
AC 100-240
50/60Hz
~
5
