Pos. B
Pos. A
+
-
B
AUX
C
NC/NO
Positive power input 12 V
Negative power input12 V
Positive input to detect when the control unit is armed.
When the control unit is disarmed input B must be closed to
a positive; in this condition the detector will operate as
bellow:
•alarm output is always closed ( it is active after 5 seconds
that terminal B is opened.).
•LED an Buzzer are always ready to signal an intrusion in
the detection area.
Input to connect an external detector for AND combination
(see DIP 3 function)
Alarm output, selectable C/NC or C/NO by jumper S3.
S1
S2
S3
RESET
Close
Open
Close
Open
Pos. A
Pos. B
Close
Open
Buzzer enabled
Buzzer disabled
Red led enabled
Red led disabled
Relè C/NC
Relè C/NO
Reset CPU
Normal operation
Default
Close
Close
Pos. A
Open
