Warning
IMPORTANT
SPIDER PA must be mounted perpendicular to the floor.
At the power up SPIDER PA is in stand by mode for 30
seconds. Testing the detector is possible after this warm-up
period.
Remember:
To optmize the detection pattern and to obtain the wished
protection area, follow the steps at pag.11 (Detection range),
pag.10 (Detection Area) and pag. 8 (DIP Switch - sensitivity
adjustment)
IMPORTANT
To create an alarm cross the
detection area.
Detection by both PIR sections produces an alarm
condition.
Detection only by lower or upper PIR section does NOT
produce an alarm condition (except in SECURITY mode).
SECURITY).
Detection only by lower or upper PIR section does NOT
produce an alarm condition (except in SECURITY mode).
SECURITY).
