HS35A 7
CONNECTOR
OPTION “W”,“Y”
FLEX. CABLE
18.00
[457.20]
MIN
INSULATED, RE-SIZABLE
HOLLOW SHAFT INSERT
0.11
[2.80]
3.20
[81.30]
1.19
[30.20]
REMOVABLE
SHAFT COVER
REMOVABLE
SHAFT COVER
1.77
[44.96]
0.23
[5.80]
0.03
[0.80]
0.56
[14.20]
2.06
[52.30]
1.60
[40.60]
CONNECTOR
OPTION “A”,“B”,“E”
“F”,“J”,“K”
#8-32 x 0.190 [4.8] DP
3 PLACES
0.86
[21.80]
2.50
[63.50]
3.00
[76.20]
3.80
[96.50]
CONNECTOR
OPTION “C”,“D”,“G”
“H”,“M”,“N”
STUB SHAFT
ENGAGEMENT
MIN 1.25[31.75]
MAX 2.25[57.15]
CONNECTOR
OPTION “T”,“U”
0.58
[14.70]
OPTION “S”
SEALED
FLEXIBLE CABLE
3.38
[85.70]
3.00
[76.20]
2.20
[55.90]
4.56 [115.80]
1.78
[45.20]
1.80
[45.70]
0.67 [17.00]
45°
15°
120°
1.00 [25.40]
0.50 [12.83]
ANTI-ROTATION TETHER
OPTION “A”,“B”,“C”,“D”,“F”
2.36
[60.00]
0.67 [17.00]
3.44
[87.30]
3.38
[85.70]
3.00
[76.20]
1.00 [25.40]
45°
15°
120°
0.50
[12.83]
ANTI-ROTATION TETHER
OPTION “E”
OPTIONAL PROTECTIVE
BASKET GUARD
6.60
[167.60]
0.30
[7.50]
4.19
[106.50]
Tether/Antirotation/Protection Options
Pin & Block Tether Option “R”
CONNECTOR
OPTION “R”
0.53
[13.5]
SHEET METAL SCREW, #14
FLAT WASHER
TETHER, 8.50 C-FACE
KIT, TETHER
MOUNTING
WASHER SET, MOLDED,
1/4" HARDWARE
GROMMET NUT, 3/8" [10mm] HOLE,
1/4-20 [M6] THRD.
*NOTE: If encoder is positioned more than
0.13 [3.30] from motor, additional flat washers
may be required to achieve a “no stress”
tether position.
TETHER OPTION “A”,“B”,“C”,“D”,“M”
TETHER OPTION “E”,“M”
FAN COVER MOUNT WITH 10MM SQUARE GRILLE OPTION “1”
TETHER OPTION “F”,“M”
TETHER OPTION “A”
Motor shaft tolerance to be +0.0000/-0.0005 [+0.0000/-0.0127] per NEMA Std. MG1.
All dimensions are in inches [millimeters]. All dimensions are approx.
Nidec standard warranty applies. Copies available upon request.
Specifications subject to change without notice.
REV: 06-12-2018
8901 E. PLEASANT VALLEY ROAD
•
INDEPENDENCE, OHIO 44131-5508
TELEPHONE: (1) 216-642-1230
•
FAX: (1) 216-642-6037
E-MAIL: tachs@nidec-avtron.com
•
WEB: www.avtronencoders.com
Nidec-Avtron Makes the Most Reliable Encoders in the World
