TRIAXYS™ Directional Wave Buoy User Manual version 13
Axys Technologies Inc.
v
Fig 3: VHF antenna/IR Port: do not use
these as handles when propping open the
Fig 4: Prop open the SPA. Do Not
Remove the SPA completely.
3. Locate the Power Distribution Module: The Power Distribution Module is located beside
the TAS module as shown.
4.
Locate the Battery Connectors and plug them into the corresponding Terminals There are
four battery connectors that are labeled battery 1 thru 4. These must be plugged into the
corresponding terminals, which are also labeled (see Figures 6 & 7).
