Appendix A: Specifications
A-11
Table 2. Mounting bracket for single acting actuator
(8)(9) Mounting bracket for pneumatic actuator Code
Motoyama Mfg. 2800 series 240, 280, 330, Nihon Koso A100 series 270, 320 * TA
Motoyama Mfg. 2800 series 400, 500S, 500L, Nihon Koso A100 series 400, 500 * TB
Motoyama Mfg. 2800 series 650S, 650L TC
Motoyama Mfg. 2800 series 240, 280, 330 (with side manual) TD
Motoyama Mfg. 2800 series 400, 500S, 500L (with side manual) TE
Motoyama Mfg. 2800 series 650S, 650L (with side manual) TF
Motoyama Mfg. 3800 series (multi-spring type) N24, N28, N33S TJ
Motoyama Mfg. 2922 series (Gyrol-I) G.R.I 280H, 330H, 400HS, 400H, 500H TL
Motoyama Mfg. 3993 series (Gyrol-II) 2911-1M series 280, 330, 400 TG
Nihon Koso 5100L series 240, 280 * TP
Nihon Koso 5200L series 218, 270, 350 * TR
Masoneilan 37, 38 series #9, #11 * MA
Masoneilan 37, 38 series #13 * MB
Masoneilan 37, 38 series #15, #18 * MC
Masoneilan 37, 38 series #15, #18 (with side manual) MF
Masoneilan type 35002 series Camflex II #41/2, #6, (Valve size 1inch - 4inches) MG
Masoneilan type 35002 Camflex II #7 (Valve size 6inches - 12inches) MH
Fisher 657, 667 series size 40 FB
Fisher 657, 667 series size 45, 50 FC
Fisher 657, 667 series size 60 FD
Pentair Valve and Control Japan AK09S, AK12S, AK15S KA
Pentair Valve and Control Japan AG06S, AGN06S KG
Pentair Valve and Control Japan AG09S, AGN09S KH
Pentair Valve and Control Japan AG13S, AGN13S KJ
Pentair Valve and Control Japan AW13S KV
Pentair Valve and Control Japan AW17S KW
Pentair Valve and Control Japan AW20S KT
KITZ B series BS-2, BSW-2 B2
KITZ B series BS-3, BSW-3, Hisaka TS-6 B3
KITZ B series BS-4, BSW-4 B4
KITZ B series BS-5, BSW-5 B5
KITZ B series BS-6, BSW-6 B6
Xomox (EL-O-MATIC) E25, 40, 65, 100, 200, 350 RA
Xomox (EL-O-MATIC) E600, 950, 1600, P2500, P4000 RB
Hisaka TS-1 H1
Hisaka TS-2 H2
Hisaka TS-3 H3
Hisaka TS-4, 5 H4
Tomoe Valve Z series Z-06S, 08S, 11S, 13S EA
Tomoe Valve T-matic 3Q-1, 2, 3, 4 E3
* Select in the case of without manual handle or with manual handle mounted on top of the actuators.
