- 5 -
TX Series Torque Conversion Chart
P.S.I./FT./lbs
TX-2 TX-4 TX-8 TX-16 TX-32
Hex
3/4" to 1-13/16"
1-7/8" to 2-3/8"
All Hex Sizes
All Hex Sizes
2-5/8" to 3-15/16"
4" to 4-5/8" 2-7/16" to 4-5/8"
4-11/16" to 6-1/2"
Sizes
19 to 46MM 47 to 60MM All Hex Sizes
All Hex Sizes
65 to 100MM 105 to 115MM
80 to 115MM 115 to 155MM
P.S.I.
ft./lbs. ft./lbs. ft./lbs. ft./lbs. ft./lbs. ft./lbs. ft./lbs. ft./lbs.
1,000
192 210 395 830 1,560 1,660 N/A 3,700
1,200
230 252 475 1,001 1,870 1,992 N/A 4,440
1,400
269 294 555 1,173 2,180 2,324 N/A 5,180
1,600
307 336 630 1,344 2,495 2,656 N/A 5,920
1,800
346 378 710 1,516 2,805 2,988 N/A 6,660
2,000
385 420 790 1,688 3,120 3,320 N/A 7,400
2,200
422 462 870 1,865 3,430 3,652 N/A 8,140
2,400
461 504 950 2,042 3,740 3,984 N/A 8,880
2,600
500 546 1,025 2,219 4,050 4,316 N/A 9,620
2,800
537 588 1,105 2,396 4,365 4,648 N/A 10,360
3,000
578 640 1,185 2,574 4,675 4,980 N/A 11,100
3,200
614 681 1,265 2,775 4,990 3,560 N/A 11,840
3,400
653 724 1,345 2,976 5,300 5,644 N/A 12,580
3,600
691 766 1,420 3,177 5,610 5,976 N/A 13,320
3,800
730 809 1,500 3,378 5,925 6,308 N/A 14,060
4,000
771 855 1,580 3,580 6,235 6,650 N/A 14,800
4,200
806 894 1,660 3,735 6,550 6,983 N/A 15,540
4,400
845 937 1,740 3,891 6,860 7,315 N/A 16,280
4,600
883 980 1,815 4,046 7,170 7,648 N/A 17,020
4,800
922 1,022 1,895 4,202 7,485 7,980 N/A 17,760
5,000
964 1,070 1,975 4,358 7,795 8,360 N/A 18,500
5,200
998 1,112 2,055 4,538 8,105 8,694 N/A 19,240
5,400
1,037 1,155 2,135 4,718 8,420 9,029 N/A 19,980
5,600
1,075 1,198 2,210 4,898 8,730 9,363 N/A 20,720
5,800
1,114 1,241 2,290 5,078 9,045 9,698 N/A 21,460
6,000
1,156 1,285 2,370 5,258 9,355 10,100 N/A 22,200
6,200
1,190 1,327 2,450 5,410 9,665 10,437 N/A 22,940
6,400
1,229 1,370 2,530 5,562 9,975 10,773 N/A 23,680
6,600
1,267 1,412 2,605 5,715 10,290 11,110 N/A 24,420
6,800
1,305 1,455 2,685 5,867 10,600 11,447 N/A 25,160
7,000
1,349 1,500 2,765 6,020 10,915 11,720 N/A 25,900
7,200
1,382 1,541 2,845 6,186 11,225 12,055 N/A 26,640
7,400
1,421 1,583 2,925 6,352 11,535 12,390 N/A 27,380
7,600
1,460 1,626 3,000 6,519 11,850 12,725 N/A 28,120
7,800
1,497 1,669 3,080 6,685 12,160 13,005 N/A 28,860
8,000
1,542 1,715 3,160 6,852 12,475 13,510 N/A 29,600
8,200
1,574 1,755 3,240 7,023 12,785 13,848 N/A 30,340
8,400
1,613 1,798 3,320 7,195 13,095 14,186 N/A 31,080
8,600
1,651 1,840 3,395 7,366 13,405 14,523 N/A 31,820
8,800
1,690 1,883 3,475 7,538 13,720 14,861 N/A 32,560
9,000
1,735 1,929 3,555 7,710 14,030 15,020 N/A 33,300
9,200
1,766 1,969 3,635 7,894 14,345 15,354 N/A 34,040
9,400
1,805 2,011 3,710 8,078 14,655 15,688 N/A 34,780
9,600
1,843 2,054 3,790 8,262 14,965 16,021 N/A 35,520
9,800
1,882 2,097 3,870 8,446 15,280 16,355 N/A 36,260
10,000
1,928 2,145 3,950 8,630 15,595 16,600 N/A 37,000
