Part Numbers for Ordering (CYLINDERS)
Part TX2 TX4 TX8 TX16 TX32
1
HOUSING TX-2-C01 TX-4-C01 TX-8-C01 TX-16-C01 TX-32-C01
PISTON ROD ASSEMBLY TX-2-C03 TX-4-C03 TX-8-C03 TX-16-C03 TX-32-C03
2
PISTON ROD TX-2-C03-1 N/A N/A TX-16-C03-1 TX-32-C03-1
3
PISTON CAP N/A N/A N/A TX-16-C03-2 TX-32-C03-2
VALVE BALL N/A N/A N/A TX-16-C03-3 TX-32-C03-3
VALVE SPRING N/A N/A N/A TX-16-C03-4 TX-32-C03-4
VALVE HOLLOW LOCK N/A N/A N/A TX-16-C03-5 TX-32-C03-5
4
PISTON SEAL PLATE TX-2-C05 TX-4-C05 TX-8-C05 N/A N/A
5
SEAL RING TX-2-C07 TX-4-C07 TX-8-C07 N/A N/A
6
SLIDER TX-2-C09 TX-4-C09 TX-8-X09 TX-16-C09 TX-32-C09
7
END CAP TX-2-C11 TX-4-C11 TX-8-C11 TX-16-C11 TX-32-C11
8
RETAINING RING TX-2-C13 TX-4-C13 TX-8-C13 N/A N/A
9
LINK PIN TX-2-C15 TX-4-C15 TX-8-C15 TX-16-C15 TX-32-C15
10
END COVER TX-2-C17 TX-4-C17 N/A N/A N/A
11
RETAINING SCREWS TX-2-C21 TX-4-C21 TX-8-C21 N/A N/A
12
END COVER SCREWS TX-2-C23 TX-4-C23 N/A N/A N/A
13
BALL PLUNGER TX-2-C25 TX-4-C25 TX-8-C25 TX-16-C25 TX-32-C25
14
SLIDER PIN TX-2-C27 TX-4-C27 TX-8-C27 TX-16-C27 TX-32-C27
15
END PLUG SEAL TX-2-C29 TX-4-C29 TX-8-C29 TX-16-C29 TX-32-C29
16
ROD SEAL TX-2-C31 TX-4-C31 TX-8-C31 TX-16-C31 TX-32-C31
17
PISTON O-RING TX-2-C33 TX-4-C33 TX-8-C33 TX-16-C33 TX-32-C33
18
SWIVEL SET N/A STX-4M-4M STX-4M-4M STX-4M-4M STX-4M-4M
18
SWIVEL SET STX-4M-8M N/A N/A N/A N/A
19
COUPLER ASSEMBLY HC-S100 HC-S100 HC-S100 HC-S100 HC-S100
20
SEAL INSERTION TOOL TX-2-ST TX-4-ST TX-8-ST N/A N/A
21
END PLUG WRENCH N/A N/A N/A TX-16-EPW TX-32-EPW
