Aztech AZ-120

—– 9 —–
TECHNICAL SPECIFICATION
Kinetic Electronics Limited reserve the right to change the design or specification without prior notice.
Our AZ-TECH range of External Sound Units are designed to comply with the requirements of BS4737
and BS EN-50131-4 as Warning Devices.
The AZ-220 & AZ-320 series, when correctly configured, are considered suitable for use in Intruder
Alarm Systems intended to comply with PD6662:2004 at Security Grade 2 and 3 respectively and
Environmental Class IV
SPECIFICATION AZTECH AZTECH AZTECH
AZ-120 AZ-220 AZ-320TW
Sound Output @ 1 M 112dB 115dB 118dB
Sounder Type Single Piezo Single Piezo Twin Piezo
Strobe - Xenon tube 90 flashes / min 90 flashes / min 90 flashes / min
Indication Twin LED Twin LED Twin LED
SAB / SCB — YES YES
Timer Panel determined 15 / 9 minute cut-off + 5 second test
Tamper Optional Front and back tamper via micro-switch
Standby Battery
Type — 6.0 volt NiMH 7.2 volt NiMH
Capacity — 320 mAh 340 mAh
Current Consumption
Full Alarm 370 mA 370 mA 400 mA
Strobe 160 mA 160 mA 160 mA
Quiescent 18 mA 18 mA 18 mA
Construction Cover 3mm ABS 3mm Polycarb. / ABS 3mm Polycarb.
Back plate 3mm ABS 3mm ABS 3mm Polycarb.
PCB Cover — ABS Polycarbonate
Weatherproof coating Conformal (PCB) Conformal (PCB) Conformal (PCB)
Operating Temperature -25°C - +55°C -25°C - +55°C -25°C - +55°C
Dimensions 328 x 195 x 55mm 328 x 195 x 55mm 328 x 195 x 55mm
Security Grade / Class 1 / IV 2 / IV 3 / IV
