—– 7 —–
Connections For ‘ADE’ (Honeywell) Panels
Accenta G3 / G4, Optima, Compact, Logic 4 etc.
STROBE + NOT CONNECTED AZTECH ESU
SCB T TAMP RTN
BELL - B BELL TR -
BELL + D SUPPLY +
SCB A SUPPLY -
STROBE - STROBE -
Connections For DA Control Panels
AZTECH ESU
AT TAMP RTN
BELL BELL TR -
+ HD SUPPLY +
OV SUPPLY -
ST STROBE -
Connections For MENVIER panels
AZTECH ESU
BELL TMP TAMP RTN
BELL TRIG BELL TR -
BELL12V SUPPLY +
OV SUPPLY -
STB STROBE -
Connections For CASTLE CARE-TECH Panels
AZTECH ESU
SABT TAMP RTN
BELL BELL TR -
+ HO SUPPLY +
- HO SUPPLY -
STR STROBE -
Connections For A1 OMNICRON & MICROMARK
STROBE + NOT CONNECTED AZTECH ESU
SCB RT TAMP RTN
BELL - BELL TR -
BELL + SUPPLY +
SCB A SUPPLY -
STROBE - STROBE -
Connections For GARDINER TECHNOLOGY
STROBE + NOT CONNECTED AZTECH ESU
SAB TAMP TAMP RTN
BELL - BELL TR -
BELL + SUPPLY +
BELL HOLD - SUPPLY -
STROBE - STROBE -
Connections For SCANTRONIC Panels
AZTECH ESU
TR TAMP RTN
BELL BELL TR -
12V SUPPLY +
0V SUPPLY -
STR - STROBE -
Connections For TEXECOM Panels
Veritas, / Excel range
AZTECH ESU
C TAMP RTN
B BELL TR -
A SUPPLY +
D SUPPLY -
S STROBE -
WIRING CONNECTION GUIDE - FOR MOST POPULAR ALARM CONTROL PANELS
