b-intense
®
ZEN
b-intense Zen
6
BI04___BO
200mm
200
mm
Kabel Fußbodenheizung anschließen.
Insert cable for oor heang.
Frontstrahlerkabel einsetzen beidseig.
Hinweis: Kabel ist beim Front strahler beigepackt.
Fit front heater cables on both sides.
Note: Cable is included with the front spotlight.
Stecker zur Steuerung.
Plug to control unit.
Stecker zum Fronstrahler.
Achtung roter Punkt!
Plug to the front heater.
Aenon red dot!
Achtung: hier werden die
Frontstrahler monert.
Aenon: here the front
heater are mounted.
Achtung: hier wird die
Rückseite monert.
Aenon: here the
back is mounted.
