B meters HYDRODIGIT User Manual

19
User Manual v1.4.3
HYDRODIGIT
LORAWAN PAYLOAD EXAMPLE
Here below you can see an example of payload decoding:
Description of the payload:
Field Format Byte
Example
byte
Application code DEC 45 45
Absolute meter counter (size 1 byte LSB) HEX XX 2A
Absolute meter counter (size 1 byte) HEX XX 2F
Absolute meter counter (size 1 byte) HEX XX 00
Absolute meter counter / reverse ow (size 1 byte MSB-nibble for X/Y) HEX XY 00
Reverse ow (size 1 byte LSB) HEX YY 86
Reverse ow (size 1 byte) HEX YY 00
Reverse ow (size 1 byte) HEX YY 00
Alarms (bit 0...5)
Diameter (bit 6) HEX KK 0A
Medium (bit 7)
Temperature (size 1 byte MSB)
HEX TT 00
Temperature (size 1 byte LSB)
HEX TT CD
45 2A 2F 00 00 86 00 00 0A 00 CD
Application code 45
Absolute meter counter 002F2A -> 12074 liters
Reverse ow 000086 -> 134 liters
Absolute meter counter / reverse ow 00
Alarms 0A è 0000 |1010 so Burst alarm and wrong installation alarm
Diameter 0 (DN15);
Medium 0 (Water);
Temperature
0x00CD = 205, so +20,5°C
