No. PART NAME QTY
1 ADAPTOR ARM 2
2 M4 x 8mm PIN HEX SECURITY SCREW 4
3 M6 x 8mm PIN HEX SECURITY SCREW 4
4 2.5mm PIN HEX SECURITY KEY (FOR PART 2) 1
5 3mm PIN HEX SECURITY KEY (FOR PARTS A & B) 1
6 4mm PIN HEX SECURITY KEY (FOR PARTS 3, C & D) 1
INTERFACE KIT
A M5 X 16mm PIN HEX SECURITY SCREW 4
B M5 X 25mm PIN HEX SECURITY SCREW 4
C M6 X 16mm PIN HEX SECURITY SCREW 4
D M6 X 25mm PIN HEX SECURITY SCREW 4
E M6 X 12mm SPACER (FOR PARTS B & D) 4
