UNIVERSAL FLAT SCREEN WALL MOUNT
ULTRA-SLIM
FOR MEDIUM SCREENS
11
BT8200
PRODUCT DIMENSIONS
THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO
LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.
200mm
7.9"MAX
240mm
9.4"MAX
292mm
11.5"
14mm
0.6"
WALL PLATE
295mm
11.6"
100mm
3.9"MAX
24mm
0.9"
24mm
0.9"
133mm
5.2"
8.5mm
0.3"
230mm
9.1"
295mm
11.6"
328mm
12.9"MAX
308mm
12.1"MIN
