50
• Install child car seat with ISOFIX connector and 3 point safety belt (g. 25B)
Direction Forward facing
Install child car seat ISOFIX connector + 3 point safety belt
Secure child in child car seat 5 point harness system
• Install child car seat with 3 point safety belt (g.25C)
Direction Forward facing ONLY
Install child car seat 3 point safety belt
Secure child in child car seat 5 point harness system
7.1 (Rearward facing) Install child car seat with ISOFIX connector + 3 point
safety belt
Installation method is same as the goup 0+, for detail installation steps, please refer
to 6.3.1 to 6.3.2
ATTENTION!
Only use inner cushion for baby from birth to 6 kg.
7.2 (Forward facing) Install child car seat with ISOFIX connector + 3 point safety belt.
7.2.1 Install child car seat.
7.2.1.1 Pull rotation lever with one hand(a) and grab backrest with another hand to
rotate 180 degree in left or right direction(b) to forward facing. (g. 26)
7.2.1.2 Pull reclining lever and adjust backrest to any position of 1,2,3. (g. 27)
7.2.1.3 Place child car seat facing forward. (g. 28)
7.2.1.4 Release ISOFIX connector by pressing button (a) and then secondary lock (b). (g. 5)
7.2.1.5 Insert both ISOFIX connector into ISOFIX anchorage points until you hear
clear „click” and ISOFIX connector indicator show green color. (g. 29)
7.2.1.6 Guide diagonal belt section of 3 point safety belt through diagonal belt
guide. Let lap belt section through lap belt guide. Insert buckle tongue into vehicle
buckle until you hear a clear „click”. (g. 30)
7.2.1.7 Push child car seat in order to t vehicle seat closely. Press child car seat with
adult body weight and take back excess belt to x the car seat rmly. (g. 31)
Note: Vehicle safety belt should not have any slack and twist during the whole
installation.
