1. Handle
2. Handle button
3. Shoulder pad
4. Crotch pad
5. Buckle
6. Webbing
7. Center function adjustment
8. Adjustment webbing
9. Side webbing guide
10. Canopy
11. Headrest
12. Inner pad
13. Front webbing guide
14. Carrier shell
15. Connecting hook
16. ISOFIX connector
17. ISOFIX release button
18. ISOFIX tube button
19. Release button of carrier from base
20. Base cover
21. Indicator window of green/orange switch for carrier installed with base
22. Indicator window of ISOFIX locked
23. Adjustment button of support leg
24. Indicator window of support leg worked
