Bacchus Genius - Lamp Replacement (Models 32;40;60;80); Lamp Replacement (Model 14)

BACCHUS GENIUS ENGLISH
30
8 - HOW TO REPLACE THE LAMP
INSIDE LAMP (Mod. 32/40/60/80)
1.Remove the plug from the socket;
2.Take off the lamp-lock from its seat with a
screwdriver;
3.Take off the light screen making it move
on the right and then gently press it downward;
4.Replace the light
Invert the operation order to place the light
INSIDE LAMP (Mod. 14)
1. Remove the plug from the socket;
2. Use a tool to remove the lamp creen
retaining 3 screws;
3. Remove the lamp and replace it;
4. Reconnect the lamp and replace the
lamp screen securing it with the
retaining screws;
Invert the operation order to place the light
9 - HOW TO REPLACE THE FUSE
ATTENTION: THIS OPERATION MUST BE DONE ONLY BY AUTHORISED
TECHNICAL SERVICE OR QUALIFIED PERSONNEL.
1. Unplug the refrigerator
2. Unscrew the two screws of the controller cover ;
3. Insert the fuse;
4. Replace the cover;
