Backyard Discovery 100QT - Step 12: Lid Panel Preparation

ŗŷǻrʲ
LEAVE SLIDING LID OFF AND
MOVE TO THE NEXT STEP.
Ǣǻrƻ
ˠˡ
LID PANEL - W2A03104
3 1/2"x22 15/16"x35 7/16" (89x582x900)
LP1
(x1)
SCREW PFH BLK
8x3/4
(x2)
H100395
SLIDE STOP
(x1)
A6P00447
ĵƻˠ ʹɮˠʺ
ĵÝ^ƻŗrĵ
ˣˣ˦ ʹɮˠʺ
ǢĵÝ^rǢǻŷƻ
ˢ˨ˤ ʹɮˡʺ
ǢNNJrɟ˚ˢˀˣ˃
NOTE PILOT
HOLES.
SLIDE LID PANEL
ON TO THE COOLER.
ATTACH SLIDE STOP
TO THE SLIDE PANEL.
27
