Backyard Discovery 1605022D - Page 14

UPRIGHT - W4L06890
1 3/8"x3 3/8"x89 1/2" (36x86x2274)
(1)
E1
UPRIGHT - W4L06891
1 3/8"x3 3/8"x89 1/2" (36x86x2274)
(1)
E2
UPRIGHT - W4L06892
1 3/8"x3 3/8"x89 1/2" (36x86x2274)
(1)
E3
FLOOR RAIL - W4L06898
1"x3 3/8"x42 1/8" (24x86x1070)
(1)
H1
Owner's Manual
Parts Identification
Wood Components (Not to Scale)
ANGLE BRACE - W4L13842
1 3/8"x3 3/8"x81 3/8" (36x86x2068)
(2)
E77
MONKEY BAR UPRIGHT - W4L13840
1 3/8"x3 3/8"x70 3/8" (36x86x1786)
(2)
E5
MONKEY BAR RAIL - W4L13841
1 3/8"x3 3/8"x48" (36x86x1219)
(2)
E7
END SUPPORT - W4L13843
1 3/8"x3 3/8"x46" (36x86x1168)
(1)
E50
SANDBOX SEAT - W4L06433
1"x5 1/4"x14 5/8" (24x134x370)
(2)
G2
SWING BEAM MOUNT - W4L06945
1"x5 1/4"x40 7/8" (24x134x1038)
(1)
G1
DECK BRACE - W4L06909
1"x3 3/8"x18 3/4" (24x86x475)
(4)
H2
E4
(1)
UPRIGHT - W2A01970
1 3/8"x3 3/8"x89 1/2" (36x86x2274)
14
