Backyard Discovery 1605022D - Page 26

MONKEY BAR
STEP 1
MONKEY BAR RAIL - W4L13841
1 3/8"x3 3/8"x48" (36x86x1219)
E7
(1)
TRIANGLE
PLATE BLUE 100
5 HOLE
(1)
A100309
T-NUT
5/16
(3)
H100074
309 (x1)
TRIANGLE PLATE BLUE
048 (x1)
L BRACKET 2.5x38x55x55
L BRACKET
2.5x38x55x55
(1)
A4M01048
005 (x1)
NUT BARREL - 7/8"
030 (x1)
WASHER - 8x19
008 (x1)
BOLT - 5/16x1"
074 (x3)
T-NUT - 5/16"
010 (x3)
BOLT - 1 1/2"
NOTE HOLES GO UPWARD
BOLT WH
5/16x1-1/2
(3)
H100010
BOLT WH
5/16x1
(1)
H100008
NUT BARREL
WH
5/16x7/8
(1)
H100005
WASHER
LOCK EXT
8x19
(1)
H100030
E7 (x1)
MONKEY BAR RAIL
26
