SLIDE ASSEMBLY
STEP 1
NOTE:
TIP:
SLIDE BED 8' LIME
(x1)
A6P00131
SLIDE BRACE - W100544
5/8"x3 3/8"x17 1/4" (16x86x438)
M77
(x1)
BOLT WH
5/16x1/2
(x3)
H100115
T-NUT
5/16
(x3)
H100074
PREBENDING THE ENDS WILL EASE ASSEMBLY.
074
(x3)
T-NUT - 5/16"
115
(x3)
BOLT - 1/2"
131
(x1)
SLIDE BED 8' LIME
M77
(x1)
SLIDE BRACE
PLACE 'M77' SLIDE BRACE BOARD 1/2" FROM THE BOTTOM EDGE OF THE SLIDE BED. USING THE BOARD AS A
TEMPL
ATE, MARK WHERE THE PILOT HOLES WILL BE DRILLED. USE A 3/8" DRILL BIT TO DRILL THE PILOT HOLES
INTO THE SLIDE BED. ATTACH THE SLIDE BED SUPPORT BOARD USING THE HARDWARE PROVIDED.
