Backyard Discovery 1605022D - Page 42

FLUSH O1 BOARDS TO TOP OF J1 BOARD.
APPROXIMATELY 3 1/8" - 79mm SPACING
BETWEEN PICKETS.
SCREW PFH
8x1 1/8
(14)
H100088
PICKET - W4L06901
5/8"x1 3/8"x13 1/4" (16x34x336)
(7)
O1
FORT ASSEMBLY
STEP 5
J1
WALL RAIL
O1 (x7)
PICKET
088 (x14)
SCREW - 1 1/8"
42
