Backyard Discovery 1605022D - Page 67

BOLT PTH
1/4x3/4
(12)
H100063
LADDER RUNG - W4L06913
5/8"x3 3/8"x20 1/4" (16x86x515)
(6)
M4
LIME HC ROCK #2
(2)
A6P00128
NOTE:
PLACE THE ROCKS AND HARDWARE ONTO THE M4 BOARDS
BEFORE PLACING ON J6 AND J7 BOARDS.
ARRANGE COLORS AS DESIRED.
SCREW PFH
8x1 1/4
(28)
H100087
LADDER RUNG - W4L06912
5/8"x3 3/8"x20 1/4" (16x86x515)
(1)
M3
FORT ASSEMBLY
STEP 30
BLUE HC ROCK #2
(2)
A6P00040
CRANBERRY HC ROCK #1
(2)
A6P00129
WASHER
LOCK INT
8x15
(12)
H100108
T-NUT
1/4
(12)
H100072
M3 (x1)
LADDER RUNG
087 (x28)
SCREW - 1-1/4"
M4 (x6)
LADDER RUNG
063 (x12)
BOLT - 3/4"
108 (x12)
WASHER - 8x15
072 (x12)
T-NUT - 1/4"
J6
LADDER RAIL
J7
LADDER RAIL
FINGER GRIP UPWARDS
ON ROCKS
67
