(1) SWING BEAM ASSEMBLY
STEP 22
NUT LOCK
5/16
(2)
BOLT HEX
5/16x2-3/4
(2)
WASHER
FLAT 8x27
(4)
WASHER FLAT 8x27
(4 PLCS)
BOLT HEX 5/16x2-3/4
(2 PLCS)
NUT LOCK 5/16
(2 PLCS)
TIGHTEN NOW
53
