Backyard Discovery 1905016B - Page 56

STEP 25
BOLT WH
5/16x1/2
(2)
T-NUT 5/16
(2)
(1) SPEEDY SLIDE B-L (4 PCS) - NARROW
DRILLING PATTERN
CENTER SLIDE AND
ALIGN TO DIMENSION.
DRILL 7/16" (11mm) HOLES
AND INSTALL HARDWARE
2 5/8 in
[67 mm]
3 3/8 in [86 mm]
1 in [26 mm]
T-NUT 5/16
(2 PLCS)
BOLT WH 5/16x1/2
(2 PLCS)
56
