Wood Components (Not to Scale)
OWNER'S MANUAL - PARTS IDENTIFICATION
P02
(x2)
POST - W2A03502
6"x6"x89 1/2" (152x152x2274)
P01
(x2)
POST - W2A03501
6"x6"x89 1/2" (152x152x2274)
GP2
(x2)
GABLE PANEL - W2A03500
2 13/16"x5 1/4"x80 3/16" (72x134x2037)
GP1
(x2)
GABLE PANEL - W2A03499
2 13/16"x5 1/4"x80 3/16" (72x134x2037)
CA01
(x1)
CORBEL - W2A03504
1 7/16"x5 3/8"x46 1/16" (36x136x1160)
GT1
(x4)
GABLE TRUSS - W2A03503
1 7/16"x33 5/8"x64 9/16" (36x854x1640)
