Backyard Discovery 9198012 - Page 15

STEP 2Phase 1
769 (x8)
BOLT - 3/4"
148 (x8)
NUT - 1/4"
302-3 (x2)
STRAIGHT TUBE
STRAIGHT TUBE
(x2)
A6P00302-3
NUT LOCK WZ
1/4
(x8)
H100148
BOLT PTH WZ
1/4x3/4
(x8)
H100769
THE "L" LAYOUT
SHOULD BE THE SAME
AS THE IMAGE SHOWN.
15
