STEP 5
Phase 1
START ALIGNMENT
OF HOLES FROM
THE TOP LEFT.
BACK VIEW
FACTORY INSTALLED
NUT. (BOTH CORNERS)
302-6L
(x2)
EXIT SUPPORT
SLIDE INTO GROOVE
ON EXIT SUPPORT.
TIP:
• RECOMMENDED BOLT ASSEMBLY ORDER, FROM TOP
LEFT AS
YOU ALIGN HOLES.
• MAKE SURE THE EXIT SUPPORT IS ALIGNED WITH
THE SLIDE ELBOW AS SHOWN BELOW.
• USE A SCREW DRIVER TO ALIGN HOLES.
• WHEN REMOVING SPACER, BEGIN ALIGNMENT OF
TUBE SLIDE OPENING FOR EASIER ASSEMBLY.
BOLT PTH WZ
1/4x3/4
(x7)
H100769
NUT LOCK WZ
1/4
(x5)
H100148
FRONT VIEW
EXIT SUPPORT
(x1)
A6P00302-6L
769
(x7)
BOLT - 3/4"
148
(x5)
NUT - 1/4"
TUBE SLIDE SPACER
To Next Page
