Backyard Discovery 9198074 - Parts Identification; Wood Components; Hardware Components

UPRIGHT - W4L12970
1 3/8"x3 3/8"x19 7/8" (36x86x505)
E85
(x1)
UPRIGHT - W4L12971
1 3/8"x3 3/8"x24 1/2" (36x86x623)
E86
(x1)
GROUND BOARD - W4L12969
1 3/8"x3 3/8"x14 3/8" (36x86x366)
E87
(x1)
BOLT WH BLK
5/16x2-3/4
(x4)
H100195
BOLT WH BLK
5/16x1 1/2
(x4)
H100407
BOLT WH BLK
1/4x1 1/2
(x2)
H100406
WASHER LOCK EXT BLK
8x19
(x4)
H100198
WASHER FLAT BLK
9x18
(x2)
H100474
T-NUT BLK
5/16
(x9)
H100379
NUT LOCK WZ
1/4
(x115)
H100148
BOLT PTH WZ
1/4x3/4
(x115)
H100769
BOLT PTH WZ
1/4x7/8
(x2)
H100795
NUT BARREL WH BLK
1/4x5/8
(x2)
H100404
WASHER LOCK EXT BLK
8x15
(x2)
H100400
Hardware Components
Owner's Manual
Parts Identification
Wood Components (Not to Scale)
