Backyard Discovery ASPEN - Page 12

Parts Identification
Wood Components
(NOT TO SCALE)
DP1 - TOP DOOR PANEL - W2A01596
1"x15 3/4"x21 7/16" (27x400x544)
DP2 - BOTTOM DOOR PANEL - W2A01597
1"x15 3/4"x19 3/4" (27x400x500)
(1)
(1)
WP1 - RIGHT REAR ASSEMBLY - W2A01592
44 3/8"x45"x41 3/4" (1127x1143x1061)
WP2 - LEFT FRONT WALL ASSEMBLY - W2A01594
44 3/8"x14"x41 3/4" (1127x355x1061)
WP4 - PICKET FENCE ASSEMBLY - W2A01598
2"x19"x21" (52x483x535)
WP3 - RIGHT FRONT WALL PANEL - W2A01595
1"x14"x39 3/4" (27x355x1010)
(1)
(1)
(1)
(1)
