STEP 25:
FRONT
LEFT
RIGHT
REAR
SCREW PWH
8x1/2 BLK
(2)
SCREW PWH 8x1/2 BLK
(2 PLCS)
BELL ASSEMBLY
(1 PLC)
(1) BELL ASSEMBLY - A4M00554
DO NOT OVER TIGHTEN
