BOLT WH
5/16 x 2-1/2
H100194
(x2)
METAL PARTS:
HARDWARE PARTS:
− We recommend that you have a separate table to organize the hardware.
− Hardware bags are printed with a seven-digit, alpha-numeric part number.
− You can organize your hardware by part number or group by hardware type (e.g. bolts, nuts, etc.).
− During assembly you only need to reference the last four digits of the number.
NOTE: CARTONS ARE NOT ORGANIZED BY PART OR STEP NUMBER.
− Organize metal parts by the three-digit, alpha-numeric part label on each bag (ex. A01).
− If there are multiple parts with the same part label, stack those pieces together.
− Part labels can be found on the bags of the parts.
− Keep parts in bags until required step.
− Allow yourself plenty of room - the metal pieces can take up a significant amount of space.
PRE-ASSEMBLY STEP 1 - SORTING PARTS
It is critical for ease of assembly that you take the time to sort and organize the metal and hardware.
