Backyard Discovery MINI BRUTUS - Assembly Steps; Step 1: Assemble Leg Structures

STEP 1
015 (x1)
TOP LEG
020 (x2)
LEG CONNECTING TUBE
019 (x4)
METAL BRACKET GREY
TOP LEG
(x4)
A4M01015
LEG CONNECTING TUBE
(x4)
A4M01020
NOTE: REPEAT THIS STEP 4 TIMES.
T
IP: PLACE CARRIAGE BOLT BEFORE NUT BARREL.
METAL BRACKET GREY
(x8)
A4M01019
BOTTOM LEG
(x4)
A4M01013
BOLT CARRIAGE WZ
5/16x2 1/2
(x4)
H100591
NUT BARREL WH WZ
5/16x7/8
(x8)
H100499
BOLT CARRIAGE WZ
5/16x2 3/4
(x4)
H100811
NOTE: TWO VERTICAL
HOLES TOWARD TOP
591 (x1)
BOLT CARRIAGE 5/16x2-1/2 WZ
811 (x1)
BOLT CARRIAGE 5/16x2-3/4 WZ
DO NOT FULLY TIGHTEN BOLT
AS IT WILL BE REMOVED
IN A LATER STEP.
013 (x1)
BOTTOM LEG
499 (x2)
NUT BARREL WH 5/16x7/8 WZ
16
