Backyard Discovery MINI BRUTUS - Step 3: Construct Top Bar Assembly

499 (x8)
NUT BARREL - 7/8
LEG ASSEMBLIES
SIDE BAR
(x2)
A4M01018
STEP 3
BOLT CARRIAGE WZ
5/16x2 1/2
(x8)
H100591
NUT BARREL WH WZ
5/16x7/8
(x8)
H100499
018 (x2)
SIDE BAR
435
(x1)
WARNING LABEL STICKER
591 (x8)
BOLT - 2 1/2
499 (x4)
NUT BARREL - 7/8
REMOVE ASSEMBLED
HARDWARE SHOWN AND
ATTACH BRACE TO LEGS
THEN RE-ATTACH HARDWARE.
PLACE WARNING TAG STICKER
CENTERED ON LEG AS SHOWN.
(APPROXIMATE LOCATION)
TOP BAR ASSEMBLY
WARNING LABEL STICKER
(x1)
A6P00435
18
