Parts Identification
Wood Components
(NOT TO SCALE)
U1 - WALL RAIL - W104147
3/4"x5 1/4"x37 3/8" (20x134x950)
W71 - SWING BEAM SUPPORT - W102420
2"x3 3/8"x49 5/8" (50x86x1260)
(3) FP1 - FLOOR PANEL - W104121
(2) RP1 - ROOF PANEL - W104148
(2) RP2 - ROOF PANEL - W104149
(1) RP3 - ROOF PANEL - W104152
(1) RP4 - ROOF PANEL - W104153
(1) RP5 - ROOF PANEL - W104154
(1) RP6 - ROOF PANEL - W104155
(1) DP1 - DOOR ASSEMBLY - W104183
