STEP 3
WASHER
LOCK EXT
8x19
(4)
LAG SCREW WH 5/16x2 1/2
3/&6
WASHER LOCK EXT 8x19
3/&6
LAG SCREW WH 5/16x2 1/2
3/&6
WASHER LOCK EXT 8x19
3/&6
*
*
LAG SCREW
WH 5/16x2 1/2
(4)
G12 - GROUND BOARD - W104105
1"x5 1/4"x82" (24x134x2084)

G13 - GROUND BOARD - W104106
1"x5 1/4"x82" (24x134x2084)

